| Rated Power |
10KVA/9KW |
20KVA/18KW |
30KVA/27KW |
40KVA/36KW |
| Input |
Voltage Range |
207-475Vac 3P4W+G |
| Working Frequency Range |
40-70Hz (settable) |
| Input Power Factor |
≥0.99 |
| Output |
Rated Voltage and Accuracy |
380Vac(1±1%) 3P4W+G |
| Output Frequency |
46-54Hz synchronize with mains power; 50Hz (Mains power between 40-46Hz and 54-60Hz ); 50Hz(Battery) |
| Rated Current |
15A |
30A |
45A |
61A |
| Output Power Factor |
0.9 |
| Output Harmonic Wave |
≤3% (Full R Load) |
| Crest Factor |
3: 1 |
| Output Overload |
105%±5%
125%±5%
Load>150%±5%: Convert to bypass output and alarm after 300ms. |
| Time between Mains Power and Battery |
0ms |
| Efficiency |
>92% |
>91% |
| Battery |
Rated Voltage |
192Vdc |
±192Vdc |
| Quantity |
16 |
32 |
| Charging Current |
5.5A |
1A |
7.5A |
1A |
5.5A |
| Dimension (LxWxH) mm |
533*260*501 |
560*260*717 |
710*260*717 |
710*260*717 |
| Weight |
26kg |
72kg |
57.5kg |
98kg |
58.5kg |
62kg |
| Working Temperature |
0℃~40℃ |
| Working Humidity |
20%~95% (non-condensing) |
| Noise |
≤60dB |
