| Model | E-WB 8.2KVA | E-WB 10.2KVA |
|---|---|---|
| Max.PV Power | 8200W | 10200W |
| Rated Power | 8200VA | 10200VA |
| Max.Charge Current | 160A | 160A |
| Battery Voltage | 48VDC | 48VDC |
| Floating Charge Voltage | 54VDC | 54VDC |
| Overcharge Protection | 63VDC | 63VDC |
| Battery Type | Compatible with GEL, AGM, Lithium Battery | |
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280VAC(For Personal Computers);90-280 VAC (For Home Appliances) | |
| Frequency Range | 50/60Hz (Auto sensing) | |
| Efficiency(AC Mode) | 98% | |
| AC Voltage Regulation (Batt Mode) | 230 VAC ± 5% | |
| Surge Power (Peak) | 16400VA | 20400VA |
| Efficiency | 90%-94% | |
| Transfer Time | 10 ms(for Personal Computers);20 ms (for Home Appliances) | |
| Waveform | Pure sine wave | |
| Full Load | 8200VA | 10200VA |
| Maximum Main Load | 8200VA | 10200VA |
| Maximum Second Load (Battery Mode) | 2800W | 3400W |
| Main Load Cut Off Voltage | 44VDC | 44VDC |
| Main Load Return Voltage | 54VDC | 54VDC |
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 5400W*2 | 5400W*2 |
| Max. input Current | 18A | 18A |
| MPPT Range @ Operating Voltage | 90-450VDC | 90-450VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC | |
| Maximum Solar Charge Current | 160A | 160A |
| Maximum AC Charge Current | 140A | 140A |
| Maximum Charge Current | 160A | 160A |
| Packing Dimension(D×W×Hmm) | 700510232 | 700513232 |
| Net Weight (kgs) | 17.2 | 19.1 |
| Network Communication Interface | USB/RS232/WiFi/GPRS | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operating Temperature | -10℃ to 50℃ |
|
| Storage Temperature | -10℃ to 60℃ |
|
