PV
(DC Input) |
Recommend max. PV input power (DC input) |
2000W / 1.2kW |
3000W / 3kW |
8000W / 6kW |
| Max. input voltage (Voc) |
60V |
145V |
500V |
| MPPT operating voltage range |
15V-60V (20V start up) |
30V-120V (30V start up) |
85V-450V (85V start up) |
| Number of MPPT |
2 |
2 |
1 |
| Max. input current per MPPT |
20A |
25A |
15A |
| Max. short-circuit current per MPPT |
25A |
27A |
16A |
Gird
(AC Input
&
Output) |
Max. output power |
1200W (default 800W, adjustable) |
3600W (default 1800W, adjustable) |
11500W |
| Rated grid current |
5.2A |
13A |
50 A |
| Rated grid voltage |
230V/240V 1Φ (LN/PE) |
230V/240V 1Φ (LN/PE) |
230V/304V/400V (LN/LNR) |
| Rated frequency |
50/60Hz |
50/60Hz |
50/60Hz |
| Acceptable range |
110-280 Vac for home UPS
90-300 Vac for home inverters |
110-280 Vac for home UPS
90-300 Vac for home inverters |
110-280 Vac for home UPS
90-300 Vac for home inverters |
Battery Parameters
(Bidirection) |
Battery type |
LiFePO4 / Lead-acid |
LiFePO4 / Lead-acid |
LiFePO4 / Lead-acid |
| Battery voltage range |
42-58.4 Vdc |
42-58.4 Vdc |
42-58.4 Vdc |
| Rated Battery Voltage |
48 Vdc |
48 Vdc |
48 Vdc |
| BMS charge/discharge current |
50 A |
50 A |
120 A |
| BMS communication mode |
RS232; RS485 |
RS232; RS485 |
RS232; RS485 |
EPS Load 2
(AC Output) |
Rated output power |
1200W / 1800VA |
3000W / 3600VA |
6000W / 6600VA |
| Rated output current |
7.8 A |
15.6 A |
28.7 A |
| Parallel output voltage / Frequency |
230V/50/60Hz (PNP, NPQ) |
230V/50/60Hz (PNP, NPQ) |
230V/50/60Hz (PNP, NPQ) |
| Rated output power |
6 single phase parallel 1800VA max 5s |
6 single phase parallel 3600VA max 5s |
12 single phase parallel & 3 phase parallel 7200VA max 5s |
| Surge power (Inrush load) |
30% |
30% |
30% |
| Switching time |
10ms (typical for UPS), 20ms (typical for Home Appliances) |
10ms (typical for UPS), 20ms (typical for Home Appliances) |
10ms (typical for UPS), 20ms (typical for Home Appliances) |
| Efficiency |
Max. efficiency |
96% |
96% |
98% |
| Panel MPPT efficiency |
99% |
99% |
99.0% |
| Protection |
Surge protection |
Type II, AC Output overvoltage protection |
Type II, AC Output overvoltage protection |
Type II, AC Output overvoltage protection |
| Input protection |
Output short-circuit protection |
| IP rating |
IP67 |
IP67 |
IP65 |
| General Parameters |
Operating temperature range |
-10℃ - 50℃ |
| Max. operating humidity |
5%-95% |
| Relative altitude |
+2000m derating |
| Standby self consumption |
<6 W |
<6 W |
<8 W |
| Installation type |
Wall-mounted |
Wall-mounted |
Wall-mounted |
| Cooling mode |
Natural cooling |
Natural cooling |
Natural cooling + External Fan |
| Communication |
4G/Wi-Fi & APP |
4G/Wi-Fi & APP |
4G/Wi-Fi & APP |
Mechanical
Specifications |
Display |
None |
None |
None |
| Inverter dimensions (LWH) |
30020090 mm |
35025090 mm |
524271203mm |
| Net weight |
3 kg |
8 kg |
9.2 kg |
| Carton dimensions (LWH) |
440300110 mm |
495350140 mm |
640405220 mm |
| Gross weight |
3.6 kg |
9.1 kg |
12 kg |
| Warranty Period |
3 years Free Warranty + 2 years Extended Warranty Service |
