Model |
B50 |
|
Wheelbase |
2350mm |
|
Folded Dimensions |
2000*1800*900mm |
|
Unfolded Dimensions |
800*1650*900mm |
|
Overall Weight (excl. Battery) |
37kg (excl. Battery） |
|
Maximum Takeoff Weight |
120kg |
|
Maximum Payload |
50kg
|
|
Maximum Horizontal Speed
|
20m/s
|
|
Maximum Climb Speed
|
5m/s
|
|
Maximum Descent Speed
|
3m/s
|
|
Maximum Pitch Angle
|
35 °
|
|
Maximum Flight Altitude
|
5000m
|
|
Hover Time (Unloaded)
|
55min
|
|
Hover Time (Fully Loaded)
|
21min
|
|
Maximum Wind Resistance
|
17m/s
|
|
Flight Control System
|
Independently developed, supporting one-key takeoff/landing, autonomous cruising, return home on signal loss; programmable waypoints and route missions with real-time editing; real-time monitoring of flight status, images, videos, voltage, satellite coordinates, altitude, speed, distance, and route missions; supports nearby landing, stationary hovering, and climb return; input voltage: 12V–88V; maximum waypoints: 2000+
|
|
Compact HD Three-axis Triple-light Pan-tilt Camera
 |
|
|
Video Output Interface
|
Network port
|
|
Control Signal Input Interface
|
Network port
|
|
Operating Voltage
|
7.2V~72V
|
|
Operating Current
|
12V 334mA
|
|
Operating Temperature
|
-10 °C~+50 °C
|
|
Weight
|
176g
|
|
Dimensions
|
59mm(L)*61mm(W)*92mm(H)
|
|
Controllable Angle Range
|
Pitch axis: -90°–+10°; Yaw axis: -90°–+90°; Roll axis: -45°–+45°
|
|
Upside-down/Inverted Mounting Mode
|
Support
|
|
Global Center/One-key Down/Yaw Center
|
Support
|
|
Visible Light Camera
|
|
|
Lens Pixels
|
5 million
|
|
Video Resolution (SD Card Recording)
|
2880*1620
|
|
Lens Specification
|
1/2.8 inch
|
|
Video Storage Format
|
H265
|
|
Aperture
|
2.2
|
|
HFOV/VFOV/DFOV
|
77.4 ° /48.8 °/85.6 °
|
|
Photo Storage Format
|
JEPG
|
|
Zoom Factor
|
30x digital zoom
|
|
Supported Memory Card Type
|
MicroSD (up to 128GB)
|
|
Video Transmission Resolution
|
1280*720
|
|
Supported File System
|
FAT32
|
|
Thermal Imaging Camera |
|
|
Resolution |
640*512 |
|
Aperture |
F=1.0 |
|
Focal Length |
9.1mm |
|
FOV |
24.8 °*18.7 ° |
|
Aperture |
F=1.0 |
|
Pixel Pitch |
12um |
|
Frame Rate |
30Hz |
|
Spectral Range |
8~14um |
|
Thermal Time Constant |
<10ms |
|
Field of View |
48.7 °x38.6 ° |
|
Focal Length |
9.1mm |
|
Detection Range |
1.1KM |
|
Laser Ranging
|
|
|
Eye Safety Class |
Class 1 |
|
Detection Range |
5M~1000M |
|
Wavelength |
905nm |
|
Ranging Accuracy |
± 1m |
|
Laser Divergence Angle |
5mrad |
|
Measurement Frequency |
1~5Hz |
|
Transmission Aperture |
10x7.5mm |
|
Accuracy |
≥98% |
|
Reception Aperture |
15x10mm |
|
False Alarm Rate |
≤1% |
|
Remote Controller |
|
|
Display |
7-inch high-brightness screen |
|
Screen Resolution |
1920*1200 |
|
Processor |
Qualcomm 6nm processor |
|
System Type |
Android 13 |
|
Dimensions |
277(L)*138(W)*96(H)mm |
|
Weight |
1.2kg |
|
Battery Life |
8~12 h |
|
RAM |
8G |
|
Storage |
128G |
|
Operating Frequency |
1.4Ghz |
|
Channels |
21 |
|
RF Power |
23dBm@CE/FCC |
|
Control Range |
5-30KM(ground-to-air, line of sight) |
